LS Series Stainless Steel Doors

FEATURES AND BENEFITS

Cores available

Polyurethane

Steel stiffened

Standard construction

Flush Top Channel and Visible Seam.

Inverted Bottom Channel (Approximate depth 9⁄16")

16 gage mortise lock reinforcement with provisions for Gov’t Series 86 mortise lockset and ANSI A115.1 lock front (1 1⁄4" x 8").

Continuous 14 gage steel integral mortise lock reinforcement with provisions for government series 86 mortise lockset and ANSI A115.1 lock front (1 1⁄4"x 8").

Doors have provisions for 4 1⁄2" full mortise Heavy Weight or Standard Weight hinges with 1⁄4" hinge backset. Doors are not handed and use hinge fillers. DL Series (shown)

Continuous 16 gage steel integral lock channel reinforcement with provisions for government series 160 or 161 cylindrical locksets (2-3/4" backset) and ANSI A115.2 lock front (1 1⁄8" x 2 1⁄4"). DL Series (shown)

Lever Lock Prep—161 DT (Modified 161 Prep) Conforms with ANSI 115.18 161 Lever lock specs. WARNING: Use Rose Trim with a minimum diameter of 3 5⁄16" to cover prep.
